TECHNICAL PAPER



           6.  IMPACT & BLAST LOADING BEHAVIOR                    the cracks observed were oriented in both the perpendicular
                                                                  and longitudinal to the direction of loading in dynamic tests.
           Infrastructure is subjected to different types of loadings and   However, in the case of quasi-static tests, the longitudinal cracks
           one of them is impact and blast for which the materials have to   were not observed.
           withstand. The high-energy dissipation and damage tolerance
                                                                            [55]
           property of ECC compared to conventional concrete makes it   Yang and Li  developed two impact resistant ECC mixtures by
           suitable to use for impact and blast resistant structures.   tailoring micromechanical properties and demonstrated their
                                                                  impact behavior at high strain rates of magnitude ranging from
                                                                   −5
           6.1  Impact and Blast Behavior of ECC Elements         10  to 10  s . Finally, the study concluded that the impact load
                                                                           −1
                                                                         −1
                                                                  carrying capacity and energy dissipation of RECC beams were
           Generally, ECC elements such as beams and panels showed   enhanced significantly compared to that of RC beams.
           improved impact and blast load carrying capacity, ductility and
                                                                            [56]
           cracking behavior than concrete elements. Few studies (see   Zhang et al.  evaluated the response of impact loading on
           Table 5) have investigated the impact and blast response of ECC   ECC blast panels with different thickness and compared with
           against concrete as their major interest.              RC panels of constant thickness. The study concluded that
                                                                  the presence of ECC enhances the cracking behavior, impact
           Maalej et al.  investigated the ballistic impact resistance of   resistance and energy absorbing capacity against multiple
                     [53]
           ECC by conducting pneumatic gun tests with prismatic panels.   impacts compared to the RC panels.
           The study concluded that very little spalling, no fragmentation,
                                                                           [57]
           very small crater size, no scabbing and significant enhancement   Nam et al.  investigated the impact resistance of ECC
           in cracking behavior of ECC specimen were observed.    specimens against plain concrete specimens under high
                                                                  impact velocity and reported that the failure such as scabbing,
           Michtcherine et al.  investigated the dynamic properties of a   perforation and formation of radial cracks was eliminated due to
                          [54]
           Hopkinson bar at high strain rates and compared them against   the multiple cracking property of ECC more than plain concrete
           the quasi-static uniaxial tensile tests. The study reported that   specimen.


           Table 5: Impact and Blast Behavior of ECC Elements
            sl.                    type of    dimensions    loading
            no.    referenCes     speCimen      (mm)       rate          oBjeCtive               oBservations
            1.     Maalej et al.  [53]  Prismatic   c/s - 300×170  300-700 m/s  To investigate ECC for its   It exhibits a higher strain capacity of 4%.
                                               *
                                    panels   t -55, 75, 100,      potential as impact and blast
                                              *
                                                                  resistant material.
                                               120&150
            2.   Mechtcherine et al.  [54]  Cylinder with   D - 75  140-180 s -1  To investigate the mechanical   The specific fracture energy obtained
                                                 *
                                  and without   l - 250           behavior of ECC using dynamic   for notched specimens was 5500 N/m,
                                                *
                                    notch                         loading and compared with   which is 50 times higher than that of
                                                                  quasi-static loading method.  conventional concrete.
            3.     Yang and Li  [55]  Beams     l - 305   10  to    To investigate the impact   i)   The load carrying capacity and
                                                            −5
                                                *
                                                            −1
                                                d - 51    10  s −1  resistance of ECC under high   energy dissipation of RECC beams
                                                 *
                                                                  loading rate.             increased by 32% and 500%,
                                                h - 76
                                                *
                                                                                            respectively compared to RC beams.
                                                                                          ii)   The structural load and energy
                                                                                            capacities enhanced by the addition
                                                                                            of steel reinforcement in RECC
                                                                                            beams more than RC beams.
            4.     Zhang et al.  [56]  Panels   h -2000     -     To evaluate the damage and   ECC exhibits smaller indentation depth
                                                *
                                               w - 1000           failure response of ECC blast   and crater size on the impact face and
                                                *
                                                                  panels and compared with   smaller exit crater on the distal face.
                                               t - 100
                                                *
                                                                  conventional RC blast panels.
            5.      Nam et al. [57]  Beams     h*-300     450 to    To investigate the impact   The ratio of mass loss of ECC specimen
                                               w*- 300    750 m/s  resistance of ECC specimens.  decreased with increase in impact
                                                                                          velocity unlike plain specimens. ECC
                                               t*- 100
                                                                                          specimens with more fibers showed
                                                                                          reduced penetration depth due to the
                                                                                          controlled scattered cracking.
           * (c/s-cross section, t-thickness, l-length, D-diameter, d-depth, h-height & w-width)
