TECHNICAL PAPER



              type of    sl.                  dimensions
             speCimen   no.  referenCes          (mm)                  oBjeCtive                  oBservations
                       14.    Cai et al. [86]  (b×d×h)*-     To investigate the hysteretic behavior of   Increase of axial load and steel tube
                                             300 × 300 × 1600  ECC-encased CFST columns under the   diameter increases the initial stiffness, load
              Columns
                                                             constant vertical load and horizontal cyclic   carrying capacity and ductility respectively.
                                                             load simultaneously.
                       15.    Xu et al.  [88]  (b×d×h)*-     To investigate the seismic behavior of ECC/ The optimum height of ECC was
                                             250 × 250 × 600  RC composite short columns.  determined as 0.8h.
                       16.    Deng and          (b×d)*-      To investigate the seismic performance   The energy dissipation and ultimate drift
                               Zhang  [89]     250 × 250     of high-ductile fiber-reinforced concrete   were increased 237% and 56.9% than RC
                                               h -500, 375   (HDC) short columns.        short column.
                                                *
            Short Columns  17.  Zhang et al. [87]  (b×d)*-   To investigate the seismic behavior of   i)  The ultimate drift ratio of the RECC and
                                               250 × 250     RECC and H-steel reinforced ECC (SRECC)   SRECC columns was enhanced 77.4%
                                               h*-500, 375   short columns.                 and 150%, respectively, than RC short
                                                                                            column.
                                                                                         ii)  The cumulative energy dissipation of
                                                                                            the RECC and SRECC short columns
                                                                                            was increased by 182% and 559%,
                                                                                            respectively at the ultimate drift ratio.
                       18.    Kesner and        (b×t×l)*-    To investigate the ECC panels by cyclic   ECC infill panels were adequate to
             Infill Panels    Billington  [91]  610 × 75 × 1220  load-displacement response.  eliminate connection failure.
                       19.    Kesner and        (b×t×l)*-    To investigate the retrofitting application of  ECC panels enhances up to 45% strength
                              Billington  [92]  610 × 75 × 1220  ECC infill panels.      than RC panels.
                       20.  Kunieda et al.  [93]  (b×t×l)*-  To develop rapid jacketing technique using  The developed technique using ECC
                                             1200 x 500 × 1600  ECC for damaged RC wall subjected to   enhances the load carrying capacity and
                                                             seismic loading.            ductility.
               Wall    21.    Li et al.  [104]  (b×t×l)*-    To investigate the seismic behavior of   Increased ultimate bearing capacity,
                                             1200 × 240 × 1000  masonry infilled walls strengthened with   stiffness and energy dissipation was
                                                             ECC.                        observed in masonry walls strengthened
                                                                                         both side with ECC.
           Masonry-Infilled   22.  Shing al.  [94]  (b×t×l)*-  To investigate the seismic performance of   The stiffness and strength of an infilled
              Frames                          60 × 94 × 197  masonry-infilled ECC and RC frames.  frame significantly increased due to the
                                                                                         incorporation of ECC and GFRP overlay
                                                                                         system.
             Dampers   23.   Nagai et al.  [95]  (b×d×l)*-400 × 150 × 3050  To investigate the structural capacity of   The maximum shear crack width and
                                          (b×d×l)*-600 × 350 × 2250  reinforced ECC dampers.  residual shear crack width observed was
                                                                                         0.08mm and 0.02mm, respectively.
            RC Buildings   24.  Fukuyama  [96]  (b×d×h)*-    To investigate the potential ECC device   ECC effectively reduced the first storey drift
            With Soft Story                 7200 × 6000 × 10800  for structural control of RC buildings with   from 2-0.5%.
                                                             soft story.
           Precast Balcony  25.  Onizuka et al.  [97]  Thickness of groove (t) -   To investigate the structural behavior of   For earthquake and wind design, the
                                                         *
                                              100, 120 & 130  ECC precast balcony.       entire specimen shows better load carrying
                                                                                         capacity.
            Building (Two   26.  Gencturk et al.  [98]  (b×d)*-  To investigate the material- and section-  i)   Depending upon the properties of
            Two-Story Two-                     82.55 × 50.8  level parameters on the structural response   ECC the stiffness and lateral strength
             Bay Frames)                                     of concrete and ECC buildings.   increases from 20-120% and 43-68%
                                                                                            than concrete respectively.
                                                                                         ii)   The increase in energy absorption
                                                                                            in terms of life safety and collapse
                                                                                            prevention limit were ∼150 and 50%,
                                                                                            respectively.
           SMA-ECC Beam  27.  Li et al.  [105]  (b×d×l)*-    To investigate the potential capacity of   SMA (Shape Memory Alloy)-ECC beams
                                             25.4 × 50.8 × 635  developed SMA-ECC beams.  exhibits higher energy dissipation capacity,
                                                                                         minimal residual deformation and self-
                                                                                         recovery of damage under cyclic loading
                                                                                         when compared with other beams.
              Beam–    28.   Liang and Lu  [99]  Beam(b×d)*-150 × 300  To investigate the seismic potential of ECC  The specimen with ECC showed enhanced
            Column–Slab                    Column(b×d)*-250 × 250  in Beam–Column–Slab subassemblies.   load carrying capacity, ultimate drift and
            subassemblies                                                                energy dissipation of 13%, 17% and 40%,
                                                                                         respectively than specimen with concrete.
            Beam–Column   29.  Lee et al.  [100]  Beam(b×d)* - 300 × 500  To investigate the seismic performance   The shear distortion to total drift of ECC
               Sub-                       Column (b×d)*- 500 × 500  of ECC joint in Beam–Column Sub-  joints decreased 85-90%compared to
            Assemblages                                      Assemblages.                concrete joints.
           (b-breadth, d-depth, l-length, t-thickness & h-height)
           *
